Description

The remotely controlled light dimming module, FIBARO Dimmer 2, is designed to work with various types of light sources. It may be connected to two-wire or three-wire configurations, so it can operate with or without a neutral lead. FIBARO Dimmer 2 can switch or dim the connected light source either through radio waves or through the wall switch connected directly to it.
The FIBARO Dimmer 2 is equipped with an algorithm for smart light source detection which makes configuration easier and ensures high compatibility of the device. It may be used as a switch with non-dimmable light sources (in 3-wire connection).

Features

Compatible with any Z-Wave or Z-Wave+ Controller
Advanced microprocessor control
Implemented algorithm for smart light source detection
Auto-adjustment of the appropriate control mode to connected load
Active power and energy metering functionality
Soft start function
Memory of the last lighting level settings
Works with various types of switches – momentary, toggle, three-way, etc.
Active element: semiconductor electronic switch
To be installed in wall switch boxes of dimensions allowing for installation, conforming to provisions of applicable regulations
This device may be used with all devices certified with Z-Wave certificate and should be compatible with such devices produced by other manufacturers

Technical data

Power supply: 100-240 V~ 50/60 Hz
Power consumption: < 1.3W
Operational temperature: 0-35°C
Dimensions (L x W x H): 42.5 x 38.25 x 20.3 mm
For installation in boxes: Ø ≥ 50mm
Operational current: 0.25-1.1A
Device temperature protection: 105°C
Overcurrent protection: requires an external 10A circuit breaker
Active element: semiconductor electronic switch
Device control: remotely via radio waves, or directly via external switch
Radio protocol: Z-Wave
Radio signal power: up to 1mW
Radio frequency: 921.42 MHz
Range: up to 30 m indoors
